Aquarium Refill Volume After Evaporation Calculator

Aquarium Refill Volume After Evaporation Calculator

Estimate RO/DI or freshwater top-off from water height drop, surface area, sump return section drop, salinity concentration, and ATO reserve days.

📌Evaporation Presets

Refill Inputs

Overflow systems usually show evaporation in the return pump chamber.
Measure the vertical drop since the last full mark.
Measure the return chamber, not the skimmer chamber.
Use net water volume after rock, substrate, and sump operating level.
Refill volume
0
gal / L
Daily evaporation
0
per day
Surface area used
0
display or return area
ATO reserve
0
days covered

Calculation Breakdown

📊Evaporation Profile Grid

0.03
covered freshwater in/day typical
0.08
open freshwater in/day typical
0.12
fan-cooled planted in/day
0.16
rimless reef in/day typical
1.05
reef sump agitation factor
1.20
warm tank factor
1.30
fish room airflow factor
1.40
dry winter room factor

🗂Measurement Mode Comparison

Display
uses full surface
Best for tanks without an overflow or sump.
Sump
uses return bay
Best for reef systems where display level stays fixed.
PPT
salinity ratio
Evaporation concentrates salt until fresh water is replaced.
ATO
reserve days
Reservoir days use measured daily loss plus a margin.

📘Refill Formula Table

Calculation stepFormulaImperial factorMetric factor
Display evaporationsurface area × height dropin² × in / 231 = galcm² × cm / 1000 = L
Sump return evaporationreturn section area × return dropin² × in / 231 = galcm² × cm / 1000 = L
Daily top-offrefill volume / elapsed daysgal per dayL per day
Reservoir capacitysafe fill volume / daily lossusable gal / gal per dayusable L / L per day
Salinity estimatetarget salinity × system volume / remaining waterppt ratioppt ratio

📏Common Tank Refill Reference

Tank sizeTypical surface0.25 in drop0.5 in drop
5.5 gal nano16 x 8 in / 41 x 20 cm0.14 gal / 0.5 L0.28 gal / 1.0 L
10 gal standard20 x 10 in / 51 x 25 cm0.22 gal / 0.8 L0.43 gal / 1.6 L
20 long30 x 12 in / 76 x 30 cm0.39 gal / 1.5 L0.78 gal / 3.0 L
40 breeder36 x 18 in / 91 x 46 cm0.70 gal / 2.7 L1.40 gal / 5.3 L
75 gal display48 x 18 in / 122 x 46 cm0.94 gal / 3.5 L1.87 gal / 7.1 L
125 gal display72 x 18 in / 183 x 46 cm1.40 gal / 5.3 L2.81 gal / 10.6 L

🧪Salinity Concentration Table

Water loss from saltwater system35 ppt becomesSG approxRefill note
1% evaporation35.4 pptabout 1.0267Small but measurable in nano reefs
3% evaporation36.1 pptabout 1.0272Top off before adjusting salt mix
5% evaporation36.8 pptabout 1.0277Common after a missed ATO refill
8% evaporation38.0 pptabout 1.0286Correct gradually if livestock are stressed
10% evaporation38.9 pptabout 1.0292Check reservoir, sensors, and pump limits

🔌ATO Reserve Planning Table

Daily evaporation3-day reserve7-day reserve10-day reserve
0.25 gal / 0.9 L0.8 gal / 2.8 L1.8 gal / 6.6 L2.5 gal / 9.5 L
0.50 gal / 1.9 L1.5 gal / 5.7 L3.5 gal / 13.2 L5.0 gal / 18.9 L
1.00 gal / 3.8 L3.0 gal / 11.4 L7.0 gal / 26.5 L10.0 gal / 37.9 L
1.50 gal / 5.7 L4.5 gal / 17.0 L10.5 gal / 39.7 L15.0 gal / 56.8 L
2.50 gal / 9.5 L7.5 gal / 28.4 L17.5 gal / 66.2 L25.0 gal / 94.6 L

💡Practical Tips

Salinity tip: For saltwater systems, replace evaporation with fresh RO/DI water. Salt does not evaporate, so adding saltwater for top-off can raise salinity further.
Sump tip: In an overflow system, the return chamber is usually the only section that drops. Measure that chamber for refill volume and ATO reserve planning.

That’s usually difficult to spot at first but then the water line drops. You might notice it when substrate becomes more visible or sump skimmer starts pulling in air. Day after day the water level gets lower. Eventually, salt levels rise and your livestock suffers.

A lot of aquarists sees the specific gravity rising and wonder what happened to their tank. Measure how far the water drop and its surface area. Do the math and it will tell you exactly how much volume has been lost.

How to Manage Water Evaporation

So know what’s leaving the system. When setting up a display, only include everything that is exposed as part of your open water. If you have a sump on a reef tank, the water level in the display rarely changes; it just goes down into return pump chamber. That make a difference in calculating the loss. Measure the width and length of the return section, NOT the main display tank. Selecting the right mode allow the calculator to perform the necessary math so you’re measuring the right amount. That’s where many people go astray, they measure the large tank and don’t understand why their top-off amounts doesn’t reflect what they see.

Once you know the volume, you need to think about daily rate. The volume doesn’t evaporate at a constant rate. That varies based off air movement, room temperature, and relative humidity. A covered freshwater tank might lose a fraction of an inch a day. A well-plumbed reef tank with lots of flow, near a ceiling fan, could easily be twice as fast (or more). It understand those evaporation profiles. It knows the effect of high humidity vs. Low humidity (a tropical room versus a dry winter house). It help you plan for your future needs.

You can say, “I’ll top off tomorrow,” instead of “Oh no! I’m down X!” This turns a chore from something you react to into something you plan for.

The effects of lackluster monitoring show themselves in salt levels. Salt doesn’t leave. Fresh water leaves. Each time you lose a drop, what’s left behind gets more concentrated. A 5 percent reduction isn’t much, is it? If so, why do the reference tables (on this page) demonstrate a rapid increase? Answer: Because 5 percent raises salinity from a comfortable 35 parts per thousand to almost 37. That’s when your corals will appear okay but they’re under stress. And that stress compound over time. You want to top off before the salinity shift enough to trip a biological alarm.

Use RO/DI water (nothing less). Never add saltwater to compensate for losses due to evaporation. That just hastens the issue.

If you’re looking to automate things, then an Automatic Top-Off (ATO) system is a life saver. However, a good one is only as good as its size. The calculator features a reserve planner that can shows you how long your reservoir will last. Simply enter your ATO container’s capacity and your tank’s net water volume. The results will tell you whether your existing setup could of withstand a 7-day vacation or if you require a bigger bottle. It would be smart to plan with some margin of safety. For example, if your stand loses two gallons per day, make sure your reservoir contains at least enough to sustain your travels for longer than that.

This tool will calculate how many days your set-up can go without refilling by taking into account the amount of water lost each day. It includes a safety buffer so you don’t wake up to an empty sump.

To keep a tank stable, you need consistency. One evaporated drop at a time, you’re fighting disorder. If you pick the correct profile for your tank and measure the drop accurately, you eliminate the guessing game. The tool gives you the numbers; you supply the observation. Note the water line. Measure the drop. Fill ‘er up. It is a routine that becomes second nature. This routine keeps your livestock healthy and your ecosystem balanced.

Water line drops, but your stress level doesn’t have to.
